With fiber glass and crepe paper as bottom material, coated with acrylic adhesive, It is widely used for motor, oil transformer insulation, etc .
The glass fibre reinforced paper tape is particularly suitable for permanent use in oil-filled transformers. It can withstand a breakdown voltage of 3,500 volts and, with a temperature resistance of up to 105 °C, belongs to insulation class A.
The paper backing is coated with a solvent-resistant acrylate adhesive, which has a high shear and tensile strength.
You can therefore use the 0.23 millimetre insulating tape wherever solvents are indispensable in the application. It also guarantees particularly good impregnation properties with resins and paints.
Datasheet
| Item No. | J-370 |
| Adhesive Type | Acrylic |
| Thickness | 0.23mm |
| Adhesion to Steel | 10 N/25mm |
| Tensile Strength | 100 N/25mm |
| Temperature Resistance | 155ºC |
| Electrical Strength | 5KV |
| Length | 50M |
Feature:
· Maximum temperature resistance up to 105°C
· High dielectric strength
· Low elongation
· High tensile strength
Advantages
· Adhesive with high shear strength
· High solvent and chemical resistance
· Resistant to transformer oil
Product benefits
· Backing material: paper, glass fibre reinforced
· Acrylic adhesive
